VEVOR PM8225D - Measurement Range Specifications

18
1mF 0.001mF ±(4.0% reading +5 digits)
10mF 0.01mF
100mF 0.1mF ±(5.0% reading +5 digits)
Over voltage protection: 600V DC or AC RMS
Frequency
Range Resolution Accuracy
10Hz 0.001Hz
±(1.0% reading +5 digits)
100Hz 0.01Hz
1kHz 0.1Hz
10kHz 1Hz
100kHz 10Hz
1MHz 100Hz
10MHz 1kHz
Minimum input voltage: 200mV (RMS)
Over voltage protection: 600V DC or AC RMS
Duty ratio
Range Resolution Accuracy
1%~99% 0.1% ±(3.0% reading +5 digits)
Minimum input voltage: 200mV (RMS)
Over voltage protection: 600V DC or AC RMS
AC current
Range Resolution Accuracy
600uA 0.1uA ±(1.0% reading +5 digits)
6mA 1uA ±(1.0% reading +3digits)
60mA 10uA
600mA 100uA ±(1.2% reading +3 digits)
6A 1mA ±(1.5% reading +3 digits)
10A 10mA
Maximum input current of mA jack: 600mA（ RMS）
Maximum input current of 10A jack：10A（ RMS）
