1.The air line (hose assembly) attaches to the outlet at the front of the
Portable Compressor via a quick- fit,Foster-type locking connection. To
secure the Foster coupling, pull back on the outer casing of the female
quick-fitconnector, [fig 1] insert over the male adapter then release [fig 2].
Note: Always double-check the connection is locked in place.
2. The portable compressor hose assembly contains a strainer system.
that eliminates moisture buildup and the possibility of corrosion. It is not
important at which end of the air line the filter is placed, but it is more
practical to connect it closest to the PCP airgun [Fig3].
