B 7.4 CB transportframe
Ideal to store and transport the device compact together with it’s
accessories within pallet size 120x100cm.
__________________________________________________________________________________________
The vacuum unit has to be put with the tilting mechanism in the foundation bin, when the device can be
attached to the frame by the securing pin (1).
(1)
__________________________________________________________________________________________
Subsequently all extension beams can be placed
on the various foundation spots.
ITEM
QUAN.
DESCRIPTION
WEIGHT
kg
ART. NR
1
1 set
Transport frame
130
408012
