B 6 Transport- and manipulation possibilities
TYPE SANDWICH ROOF PANELS
type RA (1)
0,5 .. 0.7mm Steel / aluminium
PUR / EPS
0,4 .. 0.7mm Staal / aluminium
type RB (2)
0,5 .. 0.7mm Steel / aluminium
PUR / EPS
Foil
type RB (3)
0,5 .. 0.7mm Steel / aluminium
Mineral wool
0,4 .. 0.7mm Steel / aluminium
type RB (4)
0,5 .. 0.7mm Steel / aluminium
PUR / EPS
0,4 .. 0.7mm Steel / aluminium
