5
ＩＮＳＴＡＬＬA ＴＩＯＮ
1. LOCATIOＮ
VIBRA DJ scale is very robust, still it is a “precision weighing instrument” which
requires gentle operation and handling with care. Install the unit in good conditions
for optimum result. Location as followings may cause erroneous results.
1. Area having a soft floor to make the scale not
Level.
2. Area where temperature changes abruptly.
3. Area in high humidity or dusts.
4. On an unstable base or near to a source of
vibration.
5. Area exposed to a wind from a fan or an air
conditioner.
6. Area exposed to direct sunlight.
2. UNPACKING
Unpack the container carefully. Examine the packaging and the device for damage,
and report to the shipper if any. Don’t drop the scale. Check the enclosures as
follows:
1. The scale 2. The weighing pan and the pan base
3. AC adaptor 4. Operation Manual
3. LOADING WEIGHING PAN
Place the pan base packed with the weighing pan on the scale. Fix it on the shaft
by driving the knurled nut in the center. Place the weighing pan properly on the
pan base. See(a).
4. LEVELING
Watch if the scale is level. Locate the level in front of the scale, and four adjusting
legs beneath it. Drive these legs to center the bubble in blue circle of the level.
Watch if all legs are settled on the table securely. See(b).
（ｂ） （ａ）
○ ×
Level
Blue circle
Bubbl
Fixing Nut
To Next Page
