Preface
5
Meaning of symbols
Various symbols are used to provide a clear understanding of the text.
These are explained below:
• A dot is placed before lists.
A triangle marks tasks you have to perform.
An arrow refers to a different place in the text.
In addition, we use pictograms to help you easily find certain text
sections.
I
NDICATION
The words “Tip“ and “Instruction” are followed by tips or hints for
operation.
The warning triangle indicates important safety regulations. Failing to
comply with these may result in:
• serious operating malfunctions of the machine;
• damage the machine;
• injuries or accidents.
The spanner indicates tips for assembly or adjustment work.
A star indicates that examples will follow that are intended to clarify the
text.
All directional rotations are to be interpreted when facing in direction
of travel.
