Vicon RO-M EW User Manual

225 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

RO-M EW

User Manual

Item 01-2015

Print date 02.2015

Language EN

From software version V 1.11

Serial number From VN251

Reference number A138039240-1

Table of Contents

Questions and Answers:

B
brittneyaguilarAug 9, 2025
What to do if there is a difference between the flowrate on the left and the right spreading discs of Vicon RO-M EW Spreader?
- J
  Jesus FischerAug 9, 2025
  Uneven flow rates between the left and right spreading discs on your Vicon Spreader may be due to several reasons. The dosing setting or discharge points might not be set the same on both sides. Alternatively, the stop of one or both of the actuators may have been moved, or there could be a blockage on one side. To solve this, check the dosing settings and ensure they are identical on both sides. Inspect the position of the connecting points and readjust them if necessary. Also, clean the machine thoroughly to remove any blockages and replace the agitator if it's worn.
C
Courtney MillsAug 15, 2025
What to do if Vicon RO-M EW has spreading tracks visible among the crops?
- K
  Kristen MartinezAug 15, 2025
  Visible spreading tracks among crops when using the Vicon Spreader can be due to several factors. These include average fertilizer quality (granule size), using a blend of fertilizer types, using new fertilizer with old settings, using the wrong spreading chart, incorrect overlapping of the spreading pattern, incorrect horizontal/vertical settings, incorrect spreader height, incorrect working width, worn or missing vanes, unequal tire pressure on the tractor, reduced spreading disc rpm, or an improperly set discharge point or dosing mechanism. To fix this, determine the fertilizer characteristics, select the correct spreading chart, set out driving tracks properly, ensure the machine is level, set the correct working height, and check the discharge points and PTO shaft rpm.

Vicon RO-M EW Specifications

General

Brand	Vicon
Model	RO-M EW
Category	Spreader
Language	English

Summary

Preface

Safety Information

Emphasizes the importance of reading the manual for safe operation and optimal results.

Safety

General Safety Instructions and Guidelines

Covers essential safety rules, accident prevention, intended use, and user responsibilities.

Warning Stickers and Symbols

Machine Operation Safety

Covers safe practices like avoiding unsecured machines, lifting points, and proximity to moving parts.

Tractor and Workplace Safety

Safety During Maintenance and Transport

Covers safety for authorized repairs, personal protection, and machine transport.

Getting Familiar with the Machine

Control System and IsoMatch Terminal Overview

Technical Specifications

Before First Use

Machine Inspection and Initial Assembly

Covers inspecting supplied parts and basic mounting instructions for safe assembly.

Sensor and Control System Installation

Coupling Shaft and Safety Clutch Setup

Covers checking, shortening, and mounting the coupling shaft and setting the safety clutch.

Connecting to the Tractor

Safe Connection and Disconnection Procedures

System Settings

Hopper, Speed, and Alarm Configurations

Calibration and Sensor Settings

Covers reference sensor deviation, actual hopper weight, and manual calibration tests.

ISOBUS Communication and Machine Data

Spreader Calibration Procedures

Details calibration of actuators, hopper weight, and including accessory weights.

Activities Before Spreading

Fertilizer Selection and Spreading Chart Usage

Spreader Adjustment Procedures

Application Rate and Calibration Methods

Explains constant and variable application rates, manual calibration, and fine application techniques.

Spreading Pattern Testing

Driving on the Road

Use in the Field

Field Operation Safety Guidelines

Emphasizes safety with moving parts, surroundings, tractor shutdown, and environmental protection.

Machine Adjustment and Tramline Setup

Spreading Techniques and Alarms

Storing the Machine

Maintenance

General Maintenance Safety and Authorisation

Emphasizes safe repair practices and the requirement for authorized personnel.

Component Checks and Replacements

Covers checks for bolts, jamming, material contact, nitrate risks, and using original parts.

Lubrication and Oil Specifications

Hydraulic System Maintenance

Covers checking hydraulic system pressure, safety, and replacement intervals for hoses.

Dosing Mechanism and Discharge Point Checks

Focuses on checking and setting dosing mechanism, plates, and discharge point for correct operation.

Weighing Sensor Calibration

Explains setting the weighing sensor and calculating the signal value.

Troubleshooting

Troubleshooting Table

Lists common problems, their causes, solutions, and corresponding page numbers.

Common Operational Issues and Solutions
