Victa V127 - SPECIFICATION; Engine Specifications Summary

Not for
Reproduction
21
SPECIFICATION
Engine type Air-cooled, 4 stroke, OHV
Victa engine model name V127 V144 V170
Bore (mm) 61 65 70
Stroke (mm) 43.5 43.5 44.2
Displacement (cm³) 127 144 170
Max torque/rpm >6.8Nm/2500 >7.8Nm/2500 >8.8Nm/2500
Max power/rpm >2kW/3600 >2.5kW/3600 >2.8kW/3600
Normal power/rpm >2kW/2900 >2.3kW/2900 >2.6kW/2900
rpm setting 3100+/-100 rpm
3100+/-100
(Push models)
3300+/-100
(Self Propelled
models)
Oil reservoir 440 - 500ml
Air filter 2-stage foam, oiled
Fuel tank 0.8L
Net weight (kg)
8
9
Spark plug Type F5RTC
Spark plug Gap 0.7-0.8mm
Spark plug torque 16-20N.m
8
