Victor 4000 User Manual

If the direction of current clamp or current line is reversed ther
e’s a
phase value difference of 180 °, viz. adding 180°to the standard
value.
H．Configuration List
Main Unit 1
Meter Box 1
Current Clamp 2
Test Line 4（2 Red and 2 Black）
Battery 6（Alkaline Dry Battery：1.5V AA）
Description 1
Guarantee Card 1
Certification 1
Attachment：Test Wiring Reference Drawing：
AC Current Measurement AC Voltage Measurement
Test phase position of single-phase U-I Test phase position of Three-phase four-wire Ua-Ib
Determine inductive or capacitive circuit

Victor 4000 Specifications

General

Brand	Victor
Model	4000
Category	Measuring Instruments
Language	English
