Victoria Arduino Mythos User Manual

16
EN
MYTHOS
1. GENERAL INFORMATION
MANUFACTURER:
VICTORIA ARDUINO - Via M. D’Antegiano, 6 - Belforte del Chienti, Macerata - Italy
MODELS:
MYTHOS - Electronic-instantaneous coffee grinder system
2. TECHNICAL DATA
DESCRIPTION
MODEL
MYTHOS 220 MYTHOS 110
Volts (V) 230 110
Frequency (Hz) 50 60
Power (W) 800 950
El. Motor power (W) 250 250
Revolution per min. (rpm) 1400 1700
Production rate (Kg/h) 20 20
Empty weight (Kg) 19.5 19.5
Height (mm) 590 590
Width (mm) 195 195
Depth (mm) 475 475
Noise factor (dBA) 76.5 76.5
3. APPLIANCE DESCRIPTION (see page 2, Fig. 1)
4. CONTROL PANEL (see page 2, Fig. 2)
1 Body machines
2 Coffee bean holder
3 Holder lid
4 Switch
5 Control panel
6 Start-up micro-switch
7 Frontal door
8 Dynamometric presser lever
(on the appropriate model)
9 Dynamometric presser
(on the appropriate model)
10 Fork
11 Pouring lip
12 Drawer
13 Open/closer holder tab
14 Grinding adjustment knob
15 Presser adjustment knob
(on the appropriate model)
1 Liquid crystal display
2
Lit key for 1 coffee dose
3 Lit key for 2 coffee dose
4 Lit key for 3 coffee dose
5
Lit key for single pulse (“-“ key for Barista function)
6 Lit key for continued grinding (“+“key for Barista function)
5+6 Together: access to programming

Victoria Arduino Mythos Specifications

General

Burr Size	75 mm
Manufacturer	Victoria Arduino
Frequency	50/60 Hz
Grind Adjustment	Stepless
Motor Speed	1400 rpm
Voltage	220-240 V
Category	Coffee Grinder

Summary

TECHNICAL DATA

CONTROL PANEL

PRECAUTIONS AND SAFETY FEATURES

APPLICATIONS AND USE

BASIC SAFETY PRECAUTIONS

Never touch with wet hands, never use barefoot, do not unplug by cord, avoid water.

INSTRUCTIONS FOR USE

REGULATION OF THE GRIND

Adjust grinding fineness using a knob; clockwise for finer, anticlockwise for coarser.

REGULATION OF THE PRESSING POWER

Adjust pressing force using a graded screw; clockwise to increase pressure.

PROGRAMMING OF THE MACHINE

Machine operates on factory-set mode or last used settings upon startup.

DOSE SELECTION IN AUTOMATIC MODE

DOSE SELECTION IN MANUAL MODE

DOSE SELECTION IN BARISTA MODE

Displays dose time; dose adjustable with +/- keys and auto-stored.

PROGRAMMING OF GRIND TIME

Enter programming mode to set grind time for doses using specific buttons.

PROGRAMMING OF THE SINGLE IMPULSE

MANUAL, AUTOMATIC AND BARISTA MODE SELECTION

PASSWORD ENTRY

CLEANING AND MAINTENANCE

CLEANING

MAINTENANCE

IDENTIFYING BREAKDOWNS
