82
Specifications
Tip: Dimensions and specifications may vary with features, options and accessories.
HAMMER
Dimensions
Overall Length 93.8 in. (238.2 cm)
Overall Width 37 in. (94 cm)
Overall Height 45 in. (114.2 cm)
Seat Height 26.5 in. (67.3 cm) (HAMMER S)
26 in. (66 cm) (HAMMER 8-BALL)
Wheelbase 66.5 in. (168.9 cm)
Ground Clearance 5.8 in. (14.8 cm) (HAMMER S)
5.3 in. (13.5 cm) (HAMMER 8-BALL)
Rake/Trail 33° / 5.5 in. (14 cm)
Weight
Dry Weight 672 lbs. (305 kg)
Wet Weight 702 lbs. (319 kg)
Gross Vehicle Weight Rating (GVWR) 1173 lbs. (533 kg)
Maximum Load Capacity (riders, cargo,
accessories)
471 lbs. (214 kg)
Gross Axle Weight Rating (GAWR) 415 lbs. (189 kg) Front Axle
758 lbs. (345 kg) Rear Axle
Capacities
Engine Oil 5 qts. (4.73 l) / approximately 9 pts. (4.25 l) at oil
change
Fuel 4.5 gal. (17 l)
Fuel Reserve .8 gal. (3.0 l) (approximate)
Engine
Engine Type VICTORY FREEDOM 106 / 6 V-Twin
Configuration 4 Stroke 50° V-Twin
Displacement 106 cu. in. (1731 cc)
Cooling System / Oiling System Air & Oil / Wet Sump
Compression Ratio 9.4:1
Valve Train SOHC - 4 Valves Per Cylinder / Hydraulic Lifters & Cam
Chain Adjusters
Bore and Stroke 101 x 108 mm
Fuel System / Throttle Body Bore Electronic Fuel Injection / 45 mm
Exhaust System Dual-Large Bore Slash-Cut with Common Volume
Spark Plug / Gap NGK DCPR6E / .032 inch (0.8 mm)
Chassis
Front Suspension Type / Travel 43mm Inverted Telescopic Fork / 5.1 in. (13 cm)
Rear Suspension Type/Travel Single Monotube Gas / Preload Adjustable
3.9 in. (10 cm) (HAMMER S)
3.0 in. (7.5 cm) (HAMMER 8-BALL)
Swingarm Forged & Cast Aluminum with Rising Rate Linkage
Front Brakes Dual (HAMMER S), Single (HAMMER 8-BALL)
300 x 5 mm / Floating Rotor / 4 Piston Calipers
Rear Brakes Single 300 x 5 mm / Floating Rotor / 2 Piston Caliper
