Victrola MAYFIELD - Bluetooth Mode Connection; Specifications; General & Amplifier Specs; Speaker, Radio & Bluetooth Specs

11
LISTENING TO AN EXTERNAL AUDIO DEVICE (BLUETOOTH MODE)
CONNECTING VIA BLUETOOTH
1. Press POWER/FUNC button to select the Bluetooth mode.
2. Turn ON the Bluetooth function on your external device.
NOTE: The effective distance between your external device and this apparatus is 10
meters.
3. Wait a moment until “Victrola Mayfield” appears on the paired devices list, then
select “Victrola Mayfield” and allow it to connect. If a window appears and asks for a
password, simply type “0000”, then press OK on your external device.
4. Once the pairing is completed, an audible beep will sound.
5. Control playback from the unit/remote control or Bluetooth device.
6. Long press / PAIR / MEM button to disconnect the currently connected external
Bluetooth device and restart the Bluetooth pairing.
SPECIFICATIONS
GENERAL
Power Requirements..........AC 120 V~ 60 Hz
Power Consumption...........50W
Dimensions (W x H x D) ....670mm(26.4”) x 1088mm(42.8”) x 379mm(15”) approx.
Weight.................................37.55 kgs (83 lbs) approx.
AMPLIFIER
Output Power.....................10W+10W+30W(subwoofer)
Frequency Response.........60 to 20,000 Hz
SPEAKER SYSTEM
Type...................................2-way
Impedance.........................8 ohms (tweeter), 8 ohms (L&R)
4ohms (subwoofer)
FM Radio
Range................................87.5 to 108 MHz
BLUETOOTH
Bluetooth Version......................Bluetooth V5.0
Bluetooth Profiles......................A2DP, AVRCP
Bluetooth Frequency range.......2.402GHz-2.480GHz
Operating Distance...................10m (33ft.)
TURNTABLE
Turntable Stylus........................ATN3600L
