Victron energy MPPT Control display User Manual

7. Specifications
Electrical
Supply voltage range when powered from battery 6.5 - 95Vdc
Supply voltage range when powered via VE.Direct cable 5Vdc
Power consumption with back-light turned off < 0.05W
Operating temperature range -20 - +50°C (0 - 120°C)
Power cable fuse rating 100mA
Mechanical
Installation type Flush mount
Front diameter 63mm (2.5")
Front bezel 69 x 69mm (2.7x2.7")
Body diameter 52mm (2.0")
Body depth 31mm (1.2")
Power cable length 1.5m
Weight 50g
Suitability
Suitable for the entire Victron Energy BlueSolar MPPT and the SmartSolar MPPT solar charger range, with the exception of
the (since long) discontinued BlueSolar MPPT 70/15.
MPPT Control display manual
Page 14 Specifications

Victron energy MPPT Control display Specifications

General

Brand	Victron energy
Model	MPPT Control display
Category	Monitor
Language	English
