Installation of Standbase Assembly(40"/ 50"/55")46"/
Prepare to place the TV with the display side down on a flat surface. Due to the size and weight of this
TV, the use of 2 people is recommended when moving it. Ensure the table or desk you use provides
a flat, totally clean surface, and use a soft cloth between the face of the TV and the table to protect the
TV's screen.
1. Locate the bottom bracket into the gap in the bottom of the TV, and check that it is securely held in
place by its screws, as per a) below.
2. Gently slide the fitted bracket at the bottom of the TV into the slot in the base stand. Secure the base
stand using the 4 pcs supplied screws, as per b) below, and check that each screw is firmly tightened.
Installation of WallMount Assembly( 40"/46"/50"/)55"
For wall mounting with an optional bracket, please read the following instructions in conjunction with the
bracket's instructions. Make sure qualified service personnel perform the operation.
This television can be wall mounted as follows:
1.Place the LED LCD Television face down onto a solid surface. Please place some soft material over
the front of the screen to protect it from any damage. The LCD panel is a fragile component, and must
be suitably protected when removing the base stand. Be sure that no hard or sharp objects can come
into contact with the screen's surface. Do not exert pressure on the front of the unit at any time, as this
may damage the LCD screen.
2.Remove the 4 screws from the lower part of the television, where the base joins to the TV, and take
away the stand (put the stand and screws somewhere safe for future use).
3.Use the M6 screws provided to fix the TV onto a wall mounting bracket (not included) via the
four VESA standard holes on the back of the television.
a) b)
INSTALLATION
400200
