TV OPERATION
-17-
1.PICTURE MENU
Picture Mode This function is used to select the preset picture settings. (Standard/Mild/User/Dynamic)
Contrast
Brightness
Color
Sharpness
Tint
These settings are used to adjust the Contrast (0-100), Brightness (0-100),
Color (0-100), Sharpness (0-100), and Tint (0-100) values for fine adjustments of the picture.
NOTE: Tint is enabled for NTSC channels only.
Color Temp. Use this option to select and change color temperature.
Aspect Ratio
Select the picture size:Auto 4:3 16:9 Zoom Panorama. Under different channels,
optional scaling mode is different
、 、 、 、
。
Blue Screen This function is used to ON/OFF the blue back in no Signal condition.
Noise
Reduction
The DNR (Off/Low/Middle/High) reduce the noise by applying temporal and spatial noise
reduction filters to Video data.
S
c
r
e
en
Auto Adjust
Auto setting allows the PC screen of TV to self adjust. This automatically sets the Horizontal
position Vertica- position, Phase and Size.、
Horizontal
Pos.Vertical Pos.
If picture is not Ok with auto setting then adjust Horizontal position(0-100) / Vertical
position (0-100) manually to adjust the desired picture settings.
Size Phase、
Adjust the phase (0-100) and size(0-100) to remove or reduce picture noise.
Note : 1) The screen menu will be enabled for PC source only.
2.SOUND MENU
SOUND
Sound Mode This function is used to select the preset sound modes(User, Standard, Music, Movie,Sports).
EQ
The Equilizer 120Hz, 500Hz, 1.5KHz, 5KHz, 10KHz, (0-100) can be changed by other user.
Treble The treble function is used to vary the treble level from 0 - 100.
Balance User can select the left/right speaker intensity by changing balance (-50 - +50).
Volume
The main speaker volume can be adjusted by varying this volume bar (0-100).
Auto Volume
This function is used to for automatic adjustment of volume level(On/Off).
Bass
The bass function is used to vary the bass level from 0 - 100.
