INSTALLATION
-12-
PRESET MODE (PC)
NOTE: PC V.Freq.(Hz) not more than 60Hz.
1
2
3
800*600
1024*768
60
60
37.88
48.36
RESOLUTION
V.Freq.(Hz) H.Freq.(KHz)
1360*768
60
47.7
4
1280*768
60
47.3
PRESET MODE (HDMI)
1
2
3
800*600
1024*768
60
60
37.88
48.36
RESOLUTION
V.Freq.(Hz) H.Freq.(KHz)
1360*768
60
47.7
4
1280*768
60
47.3
5
1920*1080
60
67.5
5
1920*1080
60
67.5
(Only for 22"/40"/ 50"55")46"/
(Only for 19"/24"/28"/32")
VIDE O
L R
AV IN
VIDE O
L R
AV OUT
FOR 19"/22"/24"/28"
FOR 32"
FOR 40"/46"/50"/55"
