VIDEOMAN VS-902 - System Wiring Diagrams - Multiple Units; Two Cameras and Multiple Monitors Setup

System connection with two cameras and multiple monitors
IMPORTANT!! Please read page 9 & 10 for cable requirements BEFORE running cables.
JW-VP
JS-VP
JS-AP
JP-LK
BACK
MOUNT BRACKET
4B3Y2W1R LB
LB1R 2W 3Y 4B
JS-VP
JS-AP
JP-LK
JP-VD
BACK
MOUNT BRACKET
POWER SUPPLY
FOR DOOR LATCH
Ref SE-12VDC05Adpt
* When using 2 Cameras,
Replace the Connection PCB 210W
with a 2WAY (Ref VS-2WAY) PCB.
VS-905M/952M
240V AC
* NOTE 3
JP-VD
* NOTE 5
* NOTE 1
TO NEXT
MONITOR(S)
VS-905M/952M
Ref VS-210W
OUTDOOR STATION No.1
* NOTE 3
DC IN
*NOTE 4
DC IN
*NOTE 4
To Audio Handset
Ref.VS-902H
To Audio Handset
Ref.VS-902H
Fig. 13
OUTDOOR STATION No.2
Fail-Secure
Door Latch
(Ref SL-ST-160)
Fail-Secure
Door Latch
(Ref SL-ST-160)
* NOTE 5
* NOTE 1
*Broken lines indicate Shield wire
if any
Page6
