VIDEOMAN VS-902 - Cable Requirements - STAR Wiring Method; CAT5 Cable Configuration by Distance

Cable requirement – STAR Wiring method
DC IN
VS-902M/952M
MONITOR
4core
Fig8 4core
VS-902C/952C
CAMERA
Fig8
Fig. 16
Fail-Secure
Door Latch
(Ref SL-ST-160)
Fig8
An additional power supply and
Fig8 Cable is required when
JP-LK Jumper is removed.
(Indicated as broken lines of the
diagrams)
Refer to Page3 #15, Page4 #7
and Page5 Note1,2,3 of this
manual.
Fig. 17
DC IN
VS-902M/952M
MONITOR
4core
Fig8 7core
VS-902C/952C
CAMERA
Fig8
Fail-Secure
Door Latch
(Ref SL-ST-160)
Fig8 3core
VS-902H
HANDSET
Cable requirement
Based on the distance from the camera
to the furthest monitor,
 < 20M : CAT5 cable
3Y-Video
2W-GND
4B-Audio
2W-GND
1R-12VDC
1R-12VDC
Latch #1
Latch #2
Orange
W/Orange
Green
W/Green
Blue
W/Blue
Brown
W/Brown
Fig8 7core 3core
Fig8
4core
Fig. 18
4core
Fig8
Fail-Secure
Door Latch
(Ref SL-ST-160)
Fig8
CAT5 wire configuration
 < 50M :
14/020 (0.44mm
2
) shielded cable
(connect shield to 2W)
AND
RG-59/U for video signal
(connect core to 3Y & shield to 2W)
12core
3core
Fig8
7core
VS-902M/952M
Monitor with
Ref.VS-2WAY
Fig8
Fig. 19
4core
Fig8
Fail-Secure
Door Latch
(Ref SL-ST-160)
Fig8
Fig8
Fig8
4core
 < 100M :
24/020 (0.75mm
2
) shielded cable
(connect shield to 2W)
AND
RG-59/U for video signal
(connect core to 3Y & shield to 2W)
 > 100M :Contact your supplier
NOTE : Fig 8 = 2Core 24/020
( 0.75mm
2
/Core)
Page9
