Viessmann Divicon - Divicon with Mixer

22
Divicon with mixer
Note
With several Divicons, first fit the ther-
mal insulation on the right-hand Divi-
con. For the remaining Divicons, fit the
insulation from right to left
1.2.3.
A
B
3.
2.
3.
2.
1.
A
Cut off if fitting a single module to
the wall.
B
Cut out the thermal insulation if
connecting with a union nut.
Fitting the thermal insulation
(cont.)
5836498
