EA1 Extension Module Installation
Connecting the KM BUS to the Extension Modules
Legend
A Boiler control unit
B Extension kit for heating circuit with mixing valve M2
C Extension kit for heating circuit with mixing valve M3
D Extension AM1, EA1 and/or solar control module,
type SM1
