7
5774 470 - 02
EA1 Extension Module Installation
Legend
DE1 Digital input 1
DE2 Digital input 2
DE3 Digital input 3
0 - 10 V 0 - 10 V input
fÖ Power supply
fÖA Power supply for additional accessories
aBJ Programmable output
aVG KM BUS to the control unit
A Extension EA1
F1 Fuse
Note: Apply strain relief to all on-site cables.
Close any unnecessary knock-outs with cable
entries (not cut open).
Connections
Overview of Electrical Connections
CAUTION
The electronic modules are static
sensitive. To avoid damage caused by
static discharge, follow Electro-Static
Discharge safety procedures.
A
