8
Hinged doors:
To adjust door position, loosen the hex screws on
the top hinge plate and adjust the hinge as required
(5 mm left or right). Tighten the hex screws to
secure the hinge into position.
Sliding doors:
Remove cover plates by pulling them outward.
Adjust the top and bottom nuts on the suspension
bolts to adjust the vertical position of the door. When
the position is correct, tighten the nuts.
Replace the cover plates when finished.
Note!
Use two wrenches for tightening the nuts.
The nuts must be totally fixed.
Minimum force of tightening is 15 Nm.
5. Adjusting doors
