16
C
702
66
66
50 50
150150
D
B
B
709
60
155
E
D
300
1100
D
1200
C
A
B
B
E
Fig. 6
A
Frost protection for foundations (compacted
crushed stone, e.g. 0 to 32/56 mm); thickness of
layer subject to local requirements and building
regulations
B
Foundation strip
C
Gravel bed as condensate soakaway
D
Fixing points for floorstanding installation supports
E
Only for line entry below ground level: Hydraulic
connection set (accessories)
Installation sequence
Installing the outdoor unit (cont.)
5831412
Installation
