Vitotrol 100, type OT1
Only in conjunction with Vitoconnect, type OT2
8.1.
3.
2.
Fig. 11
Vitoconnect power supply
The hardwired standard socket for the plug-in power
supply unit must be near the device and freely accessi-
ble. On-site fuse protection for the socket: Max. 16 A
(US, CA: Max. 20 A).
A
Fig. 12
1. Insert the barrel plug for the plug-in power supply
unit into Vitoconnect connection
A
.
2. Plug the plug-in power supply unit for the Vitocon-
nect into the socket.
Installation sequence
Closing the device and inserting it into the… (cont.)
