Data connections with Vitoconnect, type OPTO2
Only in conjunction with heat generators with an Opto-
link interface
K
B
C
A
E
H
G
F
D
Fig. 1
A
Heat generator with control unit
B
Optolink connection line
C
Vitoconnect, type OPTO2
D
WiFi
E
WiFi router (on site)
F
Secure internet connection to the Viessmann
server
G
Viessmann server
H
Mobile network
or
WiFi connection
K
Smartphone
Data connections with Vitoconnect, type OT2
Only in conjunction with heat generators with an Open-
Therm interface
M
B
C
A
G
L
K
H
F
D
E
Fig. 2
A
Heat generator with control unit
B
OpenTherm connection line
C
Vitoconnect, type OT2
D
OpenTherm connection line
E
Vitotrol 100, type OT1
F
WiFi
G
WiFi router (on site)
H
Secure internet connection to the Viessmann
server
K
Viessmann server
L
Mobile network
or
WiFi connection
M
Smartphone
