Viessmann VITOSOLIC 200 - Scanning options; Scanning actual values

6
Press the following keys:
1. for the "Main menu".
2. OK the first three actual values will
be displayed.
3. / for additional actual values,
subject to the system equip-
ment level.
4. until the "Main menu"
appears.
"Actual values" Explanation
Tcol Collector temperature in °C
Tcol2 Collector temperature in an additional collector array in °C
Tcylb Actual cylinder temperature in °C
Tcyl2b to Tcyl4b Actual cylinder temperature for additional consumers (e.g.
DHW cylinder 2) in °C
Tby Bypass temperature in °C
T-HE Temperature in an external heat exchanger in °C
Cyl. add. Auxiliary function for DHW heating
Time
Date
Relays 1 to 7 Relay condition
Sensors 1 to 12 Temperature at the respective sensor in °C
Note
If the sensor inputs are not connected, the value for "lead
break" will be displayed.
Intens. Radiation intensity in conjunction with a solar thermal sys-
tem
Note
If the sensor inputs are not connected, the value for "lead
break" will be displayed.
A diagram in the standard display ena-
bles you to scan the collector and actual
cylinder temperatures in the course of
the day. In addition, if your heating con-
tractor has enabled the heat meter, a
diagram displays the heat volume for the
past seven days.
Press the key in succession; the fol-
lowing diagrams will be displayed:
Scanning options
Scanning actual values
