8
Press the following keys:
1. for the "Main menu".
2. for "Solar".
3. OK to confirm.
4. for "Statement".
5. OK to confirm.
6. / for additional statement val-
ues, subject to the system
equipment level.
7. until the "Main menu"
appears.
"Statement" Explanation
Colmax Maximum collector temperature in °C
Col2max Maximum collector temperature in an additional collector
array in °C
Cylmax Maximum cylinder temperature in °C
Cly2max to
Cly4max
Maximum cylinder temperature for additional consumers (e.g.
DHW cylinder 2) in °C
Relays 1 to 7 Hours run of actuators connected at relay outputs (e.g. solar
circuit pump at R1)
Days Days run, solar control unit
To reset the values, except for days
run:
Whilst the value is displayed, press the
following keys:
1. OK "Delete?""Yes" is displayed.
2. OK to confirm.
Scanning the heat meter
Press the following keys:
1. for the "Main menu".
2. for "HM".
3. OK to confirm.
4. for "HM 1" or "HM 2".
5. OK to confirm.
6. / for additional values, subject to
the system equipment level.
Scanning options
Scanning statement values
5592 613 GB
