Viessmann Vitotrol 300-E - Fitting the Mounting Base; Mounting Options; Power Supply via Plug-in Power Supply Unit; Socket Requirements

15
2x
2x
2x
1.
3.
2.
2.
A
B
Fig. 3
A
Wall mounting
B
Mounting on flush box
Power supply via plug-in power supply unit
The socket for the plug-in power supply unit must be
near the device and freely accessible. On-site fuse
protection for the socket: Max. 16 A (US, CA:
Max. 20 A).
Installation sequence
Fitting the mounting base
5839615
Installation
