6
!
Please note
Electronic modules can be dam-
aged by electrostatic dis-
charges.
Before beginning work, touch
earthed objects, such as heating
or water pipes, to discharge static
loads.
Connection
Two-core cable with a cross-section of at
least 0.75 mm; cores may be inter-
changed.
Cable length up to 50 m.
Note
Never route the cable to the remote con-
trol immediately next to 230/400 V
cables.
Installation sequence
Installing and connecting the Vitotrol 300A
5458 093 GB
