ViewSonic CDE3204 User Manual

viii
• Do not install the display in a place exposed to direct
air conditioning.
• If the display is installed in such a location, moisture
may condense inside and may cause a malfunction.
• Do not place the display in hot, oily,
humid or excessively dusty places.
• Do not install the display where insects
may enter.
• Do not install the display where it may
be exposed to mechanical vibration.
• Do not install the display in a location where it may
spear up, such as on or behind a pillar, or where you
might bump yourhead on it. It may cause injury.
Preventing the display from toppling over
To prevent the display from toppling over, secure the
display to a wall or stand.
Placement for watching
We suggest you to watch the display at a distance of
3-7 times that of the screen height, and not in excessive
brightness. It is easy to cause eye fatigue if you watch
display for too long or in a dark room. To obtain clear
picture, do not expose the screen to direct illumination or
sunlight. Use spot lighting directed down from the ceiling
if you can.
SCREEN
• Although the screen is made with high precision
technology and has effective pixels of 99.99% or
more, black dots or bright points or light (red, blue, or
green) may appear constantly on the screen. This is a
structural property of the panel and is not a malfunction.
• The screen is made with high-precision technology. To
achieve a high level of performance and picture quality,
this display’s backlight setting is set to maximize the
brightness of the display. However, uneven brightness
may be observed when the display is viewed in a dark
environment without an input source or a blank screen.
This is a normal condition, not a malfunction of the
display. To improve this condition, change the Picture
mode, Backlight setting, enable the Light Sensor, or
turn on the Power management.
• Avoid exposing the screen surface to direct sunlight. It
is likely to damage the panel.
• Do not push or scratch the screen, or place objects on
top of the display. The image may be uneven or the
panel may be damaged.
• If the display is used in a cold place, a smear may
occur in the picture or the picture may become dark. It
is not caused by a failure. This condition will improve as
the temperature rises.
• When still pictures are displayed continuously, ghosting
may occur. It should disappear after a short period of
time.
• The screen and cabinet get warm when the display is in
use. This is a normal condition.
• Spraying insect repellent with volatile material on the
screen will cause damage.
• Do not make prolonged contact with rubber or plastic
material.
Broken pieces
Do not throw anything at the display. Doing
so may break the screen glass and cause
serious injury.
If the surface of the display cracks, unplug
the AC power cord before touching the
display. Otherwise electric shock may result.
Handling of broken glass and liquid crystal leakage
If the panel gets damaged, crystalline liquid leakage may
occur, or scattered broken glass may result. Do not touch
broken glass or crystalline liquid which is toxic, with bare
hands as cuts, poisoning or skin irritation may occur. Also
do not glass fragments or leaked crystalline liquid get into
your eyes or mouth. Should either contacted your eyes or
mouth, rinse the contacted area thoroughly with water and
consult your doctor.
SERVICING
Do not attempt to repair the display
yourself, since opening the cabinet may
expose you to dangerous voltage or other
hazards. Ask qualied service personnel
to do the servicing for your display.
Replacement parts
When replacement parts are required, be sure the
service technician certies in writing that he/she has
used replacement parts specied by the manufacturer
that have the same characteristics as the original parts.
Unauthorized substitutions may cause a re, an electric
shock or other hazards.
Safety check
Upon completion of repairs to the display, ask the service
technician to perform routine safety checks (as specied
by the manufacturer) to determine that the display is safe
for operating, and to so certify.
Ask a qualied service technician to dispose of the
display.

ViewSonic CDE3204 Specifications

General

Panel life	50000 h
Pixel pitch	- mm
Response time	8 ms
Display diagonal	32 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	59.8 - 70.09 Hz
Horizontal scan range	31.47 - 63.98 kHz
LED backlighting type	Edge-LED
Supported video modes	480i, 480p, 720p, 1080i, 1080p
Display number of colors	16.78 million colors
Active display area (W x H)	698.4 x 392.85 mm
Wi-Fi	-
HDMI version	1.4
VGA (D-Sub) input ports	1
RMS rated power	20 W
Purpose	Retail
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	41 W
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Placement supported	Indoor
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	138 mm
Package width	794 mm
Package height	496 mm
Package weight	8070 g
Cables included	AC
Sustainability certificates	ENERGY STAR
Certification	UL, FCC, Energy Star 7.0, EPEAT, Mexico Energy, CE, ErP, EAC

Weight and Dimensions

Depth	57 mm
Width	733 mm
Height	431.2 mm
Weight	6300 g
