ViewSonic CDE3204 User Manual

v
Dangerous Voltage: The lightning ash with
arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of
dangerous voltage within the inside of the product
that may be sufcient level to constitute a risk of
electric shock to persons.
Instruction: The exclamation point within an
equilateral triangle is intended to alert the user to
the presence of important operating and servicing
instructions in the literature accompanying the
appliance.
1. Read these instructions completely before using the
equipment.
2. Keep these instructions in a safe place.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean with a soft, dry cloth.
7. Do not block any ventilation openings. Install the
equipment in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or
other devices (including ampliers) that
produce heat.
9. Do not attempt to circumvent the safety
provisions of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and
a third grounding prong. The wide blade and the third
prong are provided for your safety. If the provided plug
does not t into your outlet, consult an electrician for
replacement of the outlet.
10. Prevent the power cord from being tread upon or
pinched, particularly at the plug, convenience
receptacles, and the point where they exit from the
device. Be sure that the power outlet is located near
the equipment so that it is easily accessible.
11. Only use attachments/ accessories
specied by the manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus. When a cart
is used, use caution when moving the cart/ apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus when it will be unused for a
long period of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, or the unit does not
operate normally, or has been dropped.
USE
AC power Cord
Keep the following guidelines to protect the AC power
cord from being damaged. If the AC power cord is
damaged, it may result in a re or an electric shock. Stop
using it and ask your dealer or ViewSonic service center
to exchange it.
• Do not place the display where the power cord is
subject to wear or abuse.
• Do not pinch, bend, or twist the cord excessively.
• The core lines may be bared and cut, causing a short-
circuit, and resulting in a re or an electric shock.
• Do not convert or damage the power
cord.
• Avoid power cord being rolled over or
rested upon.
• When the power cord is plugged in, do
not move the display.
• Keep the power cord away from heat sources.
• When you disconnect the AC power cord, disconnect it
from the wall outlet rst.
• When disconnecting the power cord, grasp the plug
instead of pulling the power cord.
• Use only an original ViewSonic AC power cord, not
other brands. Do not use the supplied AC power cord
on any other equipment.
• The plug of power cord is intended to serve as
disconnection device And the socket-outlet shall be
installed close to the shredder for easy Access.
Wall outlet
Insert the plug fully into the outlet. If it is
loose, do not use it. Doing so may cause
arcing and result in a re. Contact your
electrician to change the outlet.
Wiring
For your safety, be sure to unplug the AC
power cord when connecting cables.
Take care not to trip on the cables. It may cause damage
to the display set.
Electric shock
Do not touch the AC power cord or the
display with a wet hand. If you plug/unplug
the AC power cord from the display with a
wet hand, it may cause electric shock.
Lightning storms
During a lightning storm, unplug the display from the wall
outlet and disconnect the antenna to prevent damage to
the display.
When not in use
If you will not be using the display set for long periods of
time, the display set should be disconnected from the AC
power outlet to prevent power line surges. The display set
is not disconnected from the AC power source when the
display set is switched off.
To disconnect the display set completel y, unplug from the
AC power outlet.
Overloading
This display set is designed to operate on a
120V AC supply only.
If there are too many appliances connected
to the same AC power outlet, it could result in
a re or an electric shock.
Important Safety Instructions

ViewSonic CDE3204 Specifications

General

Panel life	50000 h
Pixel pitch	- mm
Response time	8 ms
Display diagonal	32 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	59.8 - 70.09 Hz
Horizontal scan range	31.47 - 63.98 kHz
LED backlighting type	Edge-LED
Supported video modes	480i, 480p, 720p, 1080i, 1080p
Display number of colors	16.78 million colors
Active display area (W x H)	698.4 x 392.85 mm
Wi-Fi	-
HDMI version	1.4
VGA (D-Sub) input ports	1
RMS rated power	20 W
Purpose	Retail
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	41 W
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Placement supported	Indoor
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	138 mm
Package width	794 mm
Package height	496 mm
Package weight	8070 g
Cables included	AC
Sustainability certificates	ENERGY STAR
Certification	UL, FCC, Energy Star 7.0, EPEAT, Mexico Energy, CE, ErP, EAC

Weight and Dimensions

Depth	57 mm
Width	733 mm
Height	431.2 mm
Weight	6300 g
