Page #43 background imageLoading...
Page #43 background image
32
Remote
Control
8 s B 42 000: Disable
001: Enable
002: Pass through
Disable: RCU has no
effect on HDTV.
Enabled: RCU controls
the HDTV.
This is the power up
default on the HDTV.
Pass through: RCU has
no effect on HDTV and all
RCU command codes are
transmitted to FC via the
RS232 port.
Setup wizard 8 s C 43 000: Disable
001: Enable
(for TV)
Disable: to skip the initial
setup wizard
Tiling-Mode 8 s P 50 000: OFF
001: ON
(for DS)
Tiling-
Compensation
8 s Q 51 000: OFF
001: ON
(for DS)
Bezel width
compensation
Tiling-H by V
Monitors
8 s R 52 01x~09x: H
0x1~0x9: V
(for DS)
1. 2
nd
digital for H
monitors
2. 3
rd
digital for V monitors
Tiling-Position 8 s S 53 001~025 (for DS)
Copy the screen of
Position# to identified
display
Date 8 s V 56 0xx: Year
1xx: Month+Day
(See example in
Note)
For specific models only
Time 8 s W 57 0xx: Hour+Min
10x: Sec
(See example in
Note)
For specific models only
Restore default 8 s ~ 7E 000 Resets HDTV to factory
setting
Note:
1. Behavior at lock modes
Lock Mode Behavior
Button Lock
1. Lock all buttons of front panel and RCU, except for “Power”
2. All the SET functions should be workable via RS32, even the ones with
according hot key in RCU like Mute,…etc.
MENU Lock
1. Lock “MENU’ key of front panel and RCU
2. The Factory and Hospitality modes should not be blocked for the model
using MENU-combined key to enter these two modes. Alternative
approach will be indicated separately if any limitation by model.
POWER Lock
1. Lock “POWER” key of front and RCU.
2. The SET_POWER on/off should be workable via RS232, but does not
mean the POWER lock will be released under this case.
3. Can not be un-locked by reset in OSD setting
4. Will auto AC power-on in power-lock
5. Under power-lock, the set will not enter power saving when no PC
signal and neither not turn off when no other video signals after 15min.
Remote control disable Lock the keys on RCU, but keep the buttons of front panel workable.
