ViewSonic CDE3204 User Manual

36
Reply (Hex Format)
Name Length ID Command Type Command Value1 Value2 Value3 CR
Hex
0x38
0x30
0x35
0x72 0x62 0x30 0x36 0x37 0x0D
Example2: Get Brightness from TV-05 , but the Brightness command ID is error
and it is NOT in the command table.
Send (Hex Format)
Name Length ID Command Type Command Value1 Value2 Value3 CR
Hex
0x38
0x30
0x35
0x67 0XD3 0x30 0x30 0x30 0x0D
Reply (Hex Format)
Name Length ID Command Type CR
Hex
0x34
0x30
0x35
0x2D 0x0D
Get-function table
Set Function Length ID
Command
Type
Command
Value Range
(Three ASCII bytes)
Comments
Code
(ASCII)
Code
(Hex)
Get-Contrast 8 g a 61 000 ~ 100
Get-Brightness 8 g b 62 000 ~ 100
Get-Sharpness 8 g c 63 000 ~ 100
Get-Color 8 g d 64 000 ~ 100
Get-Tint 8 g e 65 000 ~ 100
Get-Volume 8 g f 66 000 ~ 100
Get-Mute 8 g g 67 000: Off
001: On (muted)
Get-Input select 8 g j 6A 000~ See Set-function
table
Get-Power
status: ON/STBY
8 g l 6C 001: ON
000: STBY
Exclude VT2405-1,
and VT3205
Get-Remote
control
8 g n 6E 000: Disable
001: Enable
002: Pass through
Gets RCU mode
status
Get-Power lock 8 g o 6F 000: Unlock
001: Lock
Get-Button lock 8 g p 70 000: Unlock
001: Lock
Get-Menu lock 8 g q 71 000: Unlock
001: Lock
Get-Setup wizard 8 g s 73 000: Disable
001: Enable
(for TV)
Get-PIP mode 8 g t 74 000 : OFF
001: PIP
002: PBP
(for DS)

ViewSonic CDE3204 Specifications

General

Panel life	50000 h
Pixel pitch	- mm
Response time	8 ms
Display diagonal	32 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	59.8 - 70.09 Hz
Horizontal scan range	31.47 - 63.98 kHz
LED backlighting type	Edge-LED
Supported video modes	480i, 480p, 720p, 1080i, 1080p
Display number of colors	16.78 million colors
Active display area (W x H)	698.4 x 392.85 mm
Wi-Fi	-
HDMI version	1.4
VGA (D-Sub) input ports	1
RMS rated power	20 W
Purpose	Retail
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	41 W
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Placement supported	Indoor
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	138 mm
Package width	794 mm
Package height	496 mm
Package weight	8070 g
Cables included	AC
Sustainability certificates	ENERGY STAR
Certification	UL, FCC, Energy Star 7.0, EPEAT, Mexico Energy, CE, ErP, EAC

Weight and Dimensions

Depth	57 mm
Width	733 mm
Height	431.2 mm
Weight	6300 g
