ViewSonic CDE3204 User Manual

40
ASPECT (ZOOM, SIZE) 0F
VOLUME UP (+) 10
VOLUME DOWN (-) 11
MUTE 12
CHANNEL/PAGE UP (+)/
BRIGHTNESS+
13
CHANNEL/PAGE DOWN (-)/
BRIGHTNESS-
14
POWER 15
SOURCES (INPUTS) 16
17
18
SLEEP 19
MENU 1A
UP 1B
DOWN 1C
LEFT (-) 1D
RIGHT (+) 1E
OK (ENTER, SET) 1F
EXIT 20
21
22
23
24
25
26
27
28
29
2A
2B
RED
■
(F1)
2C
GREEN
■
(F2)
2D
YELLOW
■
(F3)
2E
BLUE
■
(F4)
2F
Note:
1. This IR-pass-through code is different with RCU key code.
2. Special control sequence for POWER key under IR-pass through mode.
2-1. When display is OFF and receives the POWER code: The display will turn on
itself, then forward the POWER code to the host via RS232.
2-2. When display is ON and receives the POWER code: The display will forward
the POWER code to the host via RS232, then turns off itself.
3. The code of VOLUME UP and VOLUME DOWN will repeatedly output when
press and hold the keys.

ViewSonic CDE3204 Specifications

General

Panel life	50000 h
Pixel pitch	- mm
Response time	8 ms
Display diagonal	32 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	59.8 - 70.09 Hz
Horizontal scan range	31.47 - 63.98 kHz
LED backlighting type	Edge-LED
Supported video modes	480i, 480p, 720p, 1080i, 1080p
Display number of colors	16.78 million colors
Active display area (W x H)	698.4 x 392.85 mm
Wi-Fi	-
HDMI version	1.4
VGA (D-Sub) input ports	1
RMS rated power	20 W
Purpose	Retail
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	41 W
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Placement supported	Indoor
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	138 mm
Package width	794 mm
Package height	496 mm
Package weight	8070 g
Cables included	AC
Sustainability certificates	ENERGY STAR
Certification	UL, FCC, Energy Star 7.0, EPEAT, Mexico Energy, CE, ErP, EAC

Weight and Dimensions

Depth	57 mm
Width	733 mm
Height	431.2 mm
Weight	6300 g
