2.2 Terminal Interface Overview
Item Description
USB interface, connect USB devices such as mobile hard disk, U disk, USB
keyboard and mouse, USB drives, etc
High Definition Multimedia Interface, HDMI3 can realize MHL function,
HDMI4 (CDE8452T/SWB8452B) can realize 4Kx2K
Connected to display devices with VGA input function
Connects the device to external audio sources
Connects the device to external video sources
Touch signal input, controls an external PC once the driver has been in-
stalled (available through PC, VGA and HDMI sources).
Audio-Video combined input port
Coaxial output
Serial port interface
Connects the device to headphones or speakers
Standard RJ45 (10M/100M/1G) Internet connection interface (This network
port is only used for Embd Player)
AC power input
Power On / Off switch
