2. Display Features

This section introduces you to the features of your Display.

Note: The features or applications described in this User’s manual may vary

depending on the device model purchased.

2.1 Control Panel Overview

CDE7500

Item Description

Power port

HDMI ports

LAN port

VGA port

VGA-AUDIO port

AV-OUT port

YPbPr/YCbCr IN ports

AV-IN port

① ② ③ ④ ⑤

⑥

⑦

Item Description

AUDIO IN port

USB ports

Headset port

SPDIF port

RS232 IN/OUT port

Control Panel Overview

Terminal Interface Overview

Item Description

Power On/Standby button

Press to show the OSD (On Screen Display) menu

VOL + / VOL - button; select or adjust menu options

BRI+ / BRI- button; select or adjust menu options

Press to show Input Source menu

Indicator and remote receiver

AC Power On/Off switch

① ② ③ ② ④ ⑤

⑥ ⑦ ⑧ ⑨ ⑩ ⑫⑪ ⑬

Optional Slot in PC

ViewSonic CDE7500 User Manual

Other manuals for ViewSonic CDE7500
