ViewSonic CDE7500 User Manual

36
Reply (Hex Format)
Name Length ID Command
Type
CR
Hex
0x34 0x30
0x32
0x2D 0x0D
Set-function table
Set
Function
Length ID Command
Type
Command Value Range Comments
(ASCII) Code (ASCII) Code (Hex) (Three ASCII bytes)
Power on/ off
(standby)
8 s ! 21 000: STBY
001: ON
Exclude VT2405-1, and
VT3205
Input Select 8 s “ 22 000: TV
001: AV
003: YPbPr
004: HDMI
014: HDMI2
024: HDMI3
034: HDMI4
006: VGA1
007: OPS
017: SDM
00A: MAIN
1. No need for USB
2. For the case of two
more same sources,
the 2nd digital is
used to indicate the
extension.
3. Exclude VT2405-1,
and VT3205
Contrast 8 s # 23 000 ~ 100
Brightness 8 s $ 24 000 ~ 100
Sharpness 8 s % 25 000 ~ 100
Color mode 8 s ) 29 000: Normal
001: Warm
002: Cold
Sound 8 s - 2D 000: SRS Off
001: SRS On
(for TV)
Bass 8 s . 2E 000 ~ 100 (for TV)
Treble 8 s / 2F 000 ~ 100 (for TV)
Balance 8 s 0 30 000 ~ 100 (for TV)
Sets Balance position
Picture Size 8 s 1 31 000: FULL
001: NORMAL
002: REAL
(for DS)
OSD
language
8 s 2 32 000: English
001: French
002: Spanish
Extend the value
for more supported
languages
Power lock 8 s 4 34 000: Unlock
001: Lock
Volume 8 s 5 35 000 ~ 100
900: Volume down
(-1)
901: Volume up
(+1)
Mute 8 s 6 36 000: OFF
001: ON (mute)
Button lock 8 s 8 38 000: Unlock
001: Lock
