Making Connecons
Connecng to External Devices
HDMI IN Connecon
Media Player Connecon
Connect an HDMI cable from your
external device to an HDMI IN port on
the LED display.
PC Connecon
Connect an HDMI cable from your PC
to an HDMI IN port on the LED display.
HDMI Out
HDMI In
HDMI 1 HDMI 2
Blu-ray / DVD / DVR / Media Player
HDMI Out
HDMI In
HDMI 1 HDMI 2
Audio Connecon
Connect an audio cable from your external audio device to the Audio Out port on
the LED display.
AUDIO OUT
Stereo Amplifier
AUDIO OUT
Audio In
AUDIO OUT
Video Output Connecon
To output video via an external display device, connect an HDMI cable to the HDMI
IN port of your external display device, and the other end to the HDMI OUT port of
your LED display.
HDMI Cable
HDMI OUT
Projector
