ViewSonic TD2220 User Manual

15
Control Explanation
Dynamic Contrast allows the user to turn the contrast ratio enhancement on or
off.
Aspect ratio Selects the image size for 4:3 and full screen.
ECO Mode provides the lower power consumption by reducing the brightness.
Standard: The default brightness setting.
Optimize: Decreases the brightness by 25 %.
Conserve: Decreases the brightness by 50 %.
Setup Menu displays the menu shown below:
Language Select allows the user to choose the language used in the menus and
control screens.
Resolution Notice advises the optimal resolution to use.
OSD Position allows the user to move the OSD menus and control screens.
OSD Timeout sets the length of time the OSD screen is displayed. For example,
with a “15 second” setting, if a control is not pushed within 15 seconds, the
display screen disappears.
OSD Background allows the user to turn the OSD background On or Off.
Auto Power Off, if enabled, will power off the display automatically when no
signal is detected for 3 minutes.
Power Indicator allows the user to select the Power Indicator On/Off for Power
On/Off mode.
Memory Recall returns the adjustments back to factory settings if the display is
operating in a supported timing mode listed in the specification of this manual.
Exception: This control does not affect changes made with the Language Select
or Power Lock setting.

ViewSonic TD2220 Specifications

General

Full HD	Yes
Dimensions (WxDxH)	511 x 66 x 310 mm
Display viewable area (HxV)	477.5 x 269.2 mm
Dimensions (W x D x H) with stand	511 x 240 x 635 mm
Mean time between failures (MTBF)	40000 h
3D	No
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display diagonal	21.5 \
Touchscreen type	Tabletop
Display brightness	200 cd/m²
Display technology	LED
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display diagonal (metric)	54.61 cm
Viewing angle, horizontal	170 °
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	24 - 83 kHz
Certification	CE, CB, BSMI, PSB, SASO, C-tick, e-standby, KC, UL/cUL, FCC-B (ICES003), UL CoC, Mexico Energy, GOST-R/Hygienic, UkrSEPRO, TCO 5.2, Erp, CCC, China Energy, EPEAT Silver, WEEE, RoHS, SVHC
Product color	Black
Compatible operating systems	Windows 7
Audio input	1
USB Type-A downstream ports quantity	2
Tilt angle range	20 - 5 °
Panel mounting interface	100 x 100 mm
AC input voltage	110 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	26 W
Power consumption (PowerSave)	18 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 90 %
Package weight	6450 g
RMS rated power	4 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	240 mm
Width (with stand)	511 mm
Height (with stand)	635 mm
Weight (with stand)	4920 g
Weight (without stand)	3960 g
