ViewSonic VA702-1 User Manual

ViewSonic Corporation Confidential - Do Not Copy VA702-1_VA702b-1
9
2
nd
Source Panel
Model number Innolux MT170EN01 V4
Type TN type with LVDS interface
Active Size 337.9 (H) x 270.3 (V)
Pixel Arrangement RGB Vertical Stripe
Pixel Pitch 0.264 mm
GLASS TREATMENT Anti Glare (Hard coating 3H)
# OF BACKLIGHTS 4 CCFL edge-light (2 top / 2 bottom)
BACKLIGHT LIFE 40,000 Hours (Min) / 50,000 (Typ)
Luminance (Center) –
Condition:
CT = 6500K, Contrast = Max,
Brightness = Max
300 cd/m2 (Typ after 30 minute warm up)
250 cd/m2 (Min after 30 minute warm up)
Brightness Uniformity (13 points)
0.8 (Typ), 0.75(Min)
δ = Min Luminance of 13 points/Max
Luminance of 13 points
Contrast Ratio 500:1 (Typ), 400:1 (min)
Color Depth 16.2 million colors (6 bits + 2 bits FRC)
Viewing Angle (Horizontal)
@ CR>=10
Typical: 150º
@ CR>= 5
Typical: 170º
VIEWING ANGLE (VERTICAL)
@ CR>=10
Typical: 135º
@ CR>= 5
Typical: 155º
Response Time
10%-90% @ Ta=25°C
8 ms (Tr= 2 ms, Tf = 6 ms) (typ)
18 ms (Tr= 7 ms, Tf = 11 ms)(max)
Panel Defects Please see Panel Quality Specifications.
