ViewSonic VA702-1 - Recommended Spare Parts List

ViewSonic Corporation Confidential - Do Not Copy VA702-1_VA702b-1
42
7. Recommended Spare Parts List
Rev: 1b
Serial No. Prefix: PST
Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number#
1 KIT,ACCESSORY(INL), LE1709 A-00003039 703000000500
2 PWR CORD 10A/125V BLK 6FT UL/CSA,SVT 18x A-00003040 453070800250
3 PWRCORD 10A/250V BLK 6FT CHINA.RVV 3Gx0. RoHS Added on 9/11/06 A-00005255 453070800170R
4 KIT,ACCESSORY,VA702-INL V7,LE1709 RoHS Added on 9/11/06 A-00005274 703000000506R
5
PCBA,IF BOARD, LE1709-6A
0
B-00003041
790411300600
6 PCBA,KEYPAD BOARD, LE1709 B-00003042 790411500000
7 PCBA,KEYPAD BOARD, LE1709 RoHS Added on 9/11/06 B-00005278 790411500000R
8 PCBA,PWR&INV./B, LE1709-6A0 B-00003043 790411400600
9 PCBA,PWR&INV./B, LE1709-6A0 RoHS Added on 9/11/06 B-00005279 790411400600R
10 PCBA,IF BOARD(V7), LE1709- 6A0 RoHS Added on 9/11/06 B-00008066 790411300630R
11 BASE, LE1709 C-00003044 501240201000
12 BEZEL,FRONT(SILVER),VA702, LE1709 C-00003045 501010202700
13 COVER,BACK, LE1709 C-00003046 501020202900
14 ASSY,BASE, LE1709 RoHS Added on 9/11/06 C-00005262 714020002400R
15 ASSY,BEZEL(S),LE1709,VA702 RoHS Added on 9/11/06 C-00005263 714030002400R
16 ASSY,BACK COVER, LE1709 RoHS Added on 9/11/06 C-00005264 714050002400R
17 COVER,HINGE, LE1709 RoHS Added on 9/11/06 C-00006088 501020203000R
18 CABLE,D-SUB 15P MALE 6FT BLACK/BLUE,SZ40 CB-00003047 453010100100
19 CABLE,D-SUB 15P MALE 6FT BLACK/BLUE,SZ40 RoHS Added on 9/11/06 CB-00005254 453010100100R
20 HRN LVDS FFC 30P 234mm,RoHSACCX30234KU28 RoHS Added on 9/11/06 CB-00005259 430303000140R
21 HRN ASS'Y 4x2P 189mm UL2651#28SZ504479B, RoHS Added on 9/11/06 CB-00005260 430300800320R
22 HRN ASS'Y 1P 137mm BLACK,UL100 7 #20, RoHS Added on 9/11/06 CB-00005261 430300100210R
23 LCD PANEL 17" MT170EN01-V1(INNOLUX) E-00003048 631102070270
24 LCD PANEL 17" MT170EN01-V7-G1,AM17000057 RoHS Added on 9/11/06 E-00008006 631102071910R
25 LCD PANEL 17" MT170EN01-V7-G2,AM17000057 RoHS Added on 9/11/06 E-00008007 631102071920R
26 LCD PANEL 17" MT170EN01-V7-G3,AM17000057 RoHS Added on 9/11/06 E-00008008 631102071930R
27 SCREW,B,CROSS,T.T-4*10,BLK ,RoHS Added on 9/11/06 HW-00005265 509412610500R
28 SCREW,F,CROSS,T.T-4*10,Ni RoHS Added on 9/11/06 HW-00005266 509212610300R
29 SCREW,P,CROSS,M5*22,Ni,RoHS Added on 9/11/06 HW-00005267 509116822300R
30 SCREW,PW,CROSS,W/WAS,M3*5,NI RoHS Added on 9/11/06 HW-00005269 509146305300R
31 BOLT,#4-40x11.8,Ni FOR D-SUB/DVI CONN. RoHS Added on 9/11/06 HW-00005270 509000000700R
32 SCREW,I,CROSS,M3*4,Zw,RoHS Added on 9/11/06 HW-00005271 509016304102R
33 HINGE,RIGHT, LE1709 RoHS Added on 9/11/06 HW-00005276 502060401910R
34 HINGE,LEFT, LE1709 RoHS Added on 9/11/06 HW-00005277 502060401900R
35 GENERIC FOAM SET Added on 9/11/06 P-00001347 30833
36 GENERIC BOX Added on 9/11/06 P-00002515 20653
37
BAG,PLASTIC,L550xW450xT0.05mm,LE170
9
P-00003049
506120004300
38 CARTON,VA702, LE1709 P-00003050 506020006800
39 CARTON,VA702, LE1709 RoHS Added on 9/11/06 P-00005256 506020006800R
40 CUSHION,EPS-L, LE1709 P-00003051 506040005500
41 CUSHION,EPS-L, LE1709 RoHS Added on 9/11/06 P-00005257 506040005500R
42
CUSHION,EPS-R, LE1709
P-00003052
506040005510
43 CUSHION,EPS-R, LE1709 RoHS Added on 9/11/06 P-00005253 506040005510R
44 BAG,PE+EPE,L590xW480xT0.6mm (PRINTED)LE1 RoHS Added on 9/11/06 P-00005272 506120300400R
45 BAG,PLASTIC,l690xW(455+145)xT0.05mm, LE1 RoHS Added on 9/11/06 P-00005273 506120004500R
46 Plastics: RUBBER,FOOT,OD14.1xT2.5mm,3M, LE1708 PL-00003053 503020002600
Remark 1:
Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2:
PC Board Assembly:
Cabinets:
RECOMMENDED SPARE PARTS LIST (VA702-1)
Description
Accessories:
ViewSonic Model Number: VS10781
Cables:
Hardware:
Packing Material:
Electronic
Components:
All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic Corporation. This is to
eliminate repeated cross checks of each item between this version and prior versions.
