Disassembly Block
VA702/b (INL PANEL)DIS-ASSEMB LY BLOCK
Note: Arrows are disassembly directions.
BASE SUB-ASSM *1
HINGE COVER*2
(SCREW,P,CROSS,M5*22, Ni*4)
BEZEL SUB-ASSM *1
(SCREW,B,CROSS,T4*10, BLK*4)
HINGE,RIGHT*1
HINGE,LEFT*1
(SCREW,F,CROSS,T4*10, Ni*4)
(SCREW,I ,CROSS,M3*4,Zw*1)
BACK COVER SUB-ASS’Y*1
BEZEL
SUB-ASSM(G/S)
BUTTON FUNCTION KEY*1
LED LENS*1 FRONT BEZEL (G/S)*1
BACK COVER
SUB-ASS’Y
SUPPORT VESA *1
PLATE BASE *1
Rubber spacer*1
Logo *1
BACK COVER *1
BRACKET_R*1
GROUND WIRE*1
KEYPAD CABEL*
KEYPAD ASSM*1
(SCREW,PW,CROSS,M3*5, Ni *2)
(SCREW,I ,CROSS,M3*4,Zw*2)
(Ace tape*4)
INL PANEL*1
BRACKET_R*1
(SCREW,PW,CROSS,M3*5, Ni *2)
(SCREW,I ,CROSS,M3*4,Zw*2)
(Ace tape *2)
IF BOARD*1
POWER BOARD*1
FFC CABLE*1
CLIP,WIRE*1
(SCREW,PW,CROSS,M3*5, Ni*5)
(BOLT, #4-40x11.8, Ni*2)
INSULATOR,MYLAR*1
CHASSIS*1
BASE COVER
SUB-ASS’Y
BASE COVER *1
