ViewSonic VA702-1 - Assembly Block

ViewSonic Corporation Confidential - Do Not Copy VA702-1_VA702b-1
28
Assembly Block
VA702/b (INL panel)ASSEMBLY BLOCK
Note: Arrows are assembly directions.
CHASSIS*1
INSULATOR,MYLAR*1
IF BOARD*1
POWER BOARD*1
FFC CABLE*1
CLIP,WIRE*1
(SCREW,PW,CROSS,M3*5, Ni*4)
(BOLT, #4-40x11.8, Ni*2)
INL PANEL*1
BRACKET_L*1
(SCREW,PW,CROSS,M3*5, Ni*2)
(SCREW,I ,CROSS,M3*4,Zw*2)
(Ace tape*2)
FRONT BEZEL (G/S)*1 LED LENS*1
BUTTON FUNCTION KEY*1
LOGO PLATE,THREE BRID*1
LOGO PLATE
“VIEWSONIC”*1
BEZEL
SUB-ASSM(G/S
)
BACK COVER *1
BACK COVER
SUB-ASS’Y
LOGO PLATE(ELLIPSE)*1
Rubber*1
SUPPORT VESA *1
BRACKET_R*1
GROUND WIRE*1
KEYPAD CABEL*1
KEYPAD ASSM*1
(SCREW,PW,CROSS,M3*5, Ni*2)
(SCREW,I ,CROSS,M3*4,Zw*2)
(Ace tape*4)
BACK COVER SUB-ASS’Y*1
HINGE,RIGHT*1
HINGE,LEFT*1
(SCREW,F,CROSS,T4*10, Ni*4)
(SCREW,I ,CROSS,M3*4,Zw*1)
BEZEL SUB-ASSM *1
ID LABEL*1
(SCREW,B,CROSS,T4*10, BLK*4)
BASE SUB-ASSM *1
OPENING STAND LABEL*1
HINGE COVER*2
(SCREW,P,CROSS,M5*22, Ni*4)
BASE COVER
SUB-ASS’Y
BASE COVER *1
PLATE BASE *1
RUBBER FOOT LE1708 *4
S/N LABEL*1
QC LABEL*1
HI POT LABEL*1
V17 LCD MONITOR
FI
NAL ASM(INL)
