ViewSonic VA702-1 - Page 46

ViewSonic Corporation Confidential - Do Not Copy VA702-1_VA702b-1
43
Rev: 1b
Serial No. Prefix: PSX
Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number#
1 PWR CORD 10A/125V BLK 6FT UL/CSA,SVT 18x A-00003040 453070800250
2 KIT,ACCESSORY,VA702B-INL,LE1709 A-00003054 703000000510
3 PWRCORD 10A/250V BLK 6FT CHINA.RVV 3Gx0. RoHS Added on 9/11/06 A-00005255 453070800170R
4
PCBA,IF BOARD, LE1709-6A
0
B-00003041
790411300600
5 PCBA,KEYPAD BOARD, LE1709 B-00003042 790411500000
6 PCBA,KEYPAD BOARD, LE1709 ROHS Added on 9/11/06 B-00005278 790411500000R
7 PCBA,PWR&INV./B, LE1709-6A0 B-00003043 790411400600
8 PCBA,PWR&INV./B, LE1709-6A0 ROHS Added on 9/11/06 B-00005279 790411400600R
9 PCBA,IF BOARD(V7), LE1709- 6A0 ROHS Added on 9/11/06 B-00008066 790411300630R
10 BASE, LE1709 C-00003044 501240201000
11 COVER,BACK, LE1709 C-00003046 501020202900
12 BEZEL,FRONT(GRAY),VA702b, LE1709 C-00003055 501010202710
13 ASSY,BASE, LE1709 RoHS Added on 9/11/06 C-00005262 714020002400R
14 ASSY,BACK COVER, LE1709 RoHS Added on 9/11/06 C-00005264 714050002400R
15 COVER,HINGE, LE1709 RoHS Added on 9/11/06 C-00006088 501020203000R
16 ASSY,BEZEL(G),LE1709,VA702b RoHS Added on 9/11/06 C-00008095 714030002410R
17 CABLE,D-SUB 15P MALE 6FT BLACK/BLUE,SZ40 CB-00003047 453010100100
18 CABLE,D-SUB 15P MALE 6FT BLACK/BLUE,SZ40 RoHS Added on 9/11/06 CB-00005254 453010100100R
19 HRN LVDS FFC 30P 234mm,RoHSACCX30234KU28 RoHS Added on 9/11/06 CB-00005259 430303000140R
20 HRN ASS'Y 4x2P 189mm UL2651#28SZ504479B, RoHS Added on 9/11/06 CB-00005260 430300800320R
21 HRN ASS'Y 1P 137mm BLACK,UL100 7 #20, RoHS Added on 9/11/06 CB-00005261 430300100210R
22 LCD PANEL 17" MT170EN01-V1(INNOLUX) E-00003048 631102070270
23 LCD PANEL 17" MT170EN01-V7-G1,AM17000057 RoHS Added on 9/11/06 E-00008006 631102071910R
24 LCD PANEL 17" MT170EN01-V7-G2,AM17000057 RoHS Added on 9/11/06 E-00008007 631102071920R
25 LCD PANEL 17" MT170EN01-V7-G3,AM17000057 RoHS Added on 9/11/06 E-00008008 631102071930R
26 SCREW,B,CROSS,T.T-4*10,BLK ,ROHS Added on 9/11/06 HW-00005265 509412610500R
27 SCREW,F,CROSS,T.T-4*10,Ni ROHS Added on 9/11/06 HW-00005266 509212610300R
28 SCREW,P,CROSS,M5*22,Ni,ROHS Added on 9/11/06 HW-00005267 509116822300R
29 SCREW,PW,CROSS,W/WAS,M3*5,NI RoHS Added on 9/11/06 HW-00005269 509146305300R
30 BOLT,#4-40x11.8,Ni FOR D-SUB/DVI CONN.RoHS Added on 9/11/06 HW-00005270 509000000700R
31 SCREW,I,CROSS,M3*4,Zw,ROHS Added on 9/11/06 HW-00005271 509016304102R
32 HINGE,RIGHT, LE1709 RoHS Added on 9/11/06 HW-00005276 502060401910R
33 HINGE,LEFT, LE1709 RoHS Added on 9/11/06 HW-00005277 502060401900R
34
BAG,PLASTIC,L550xW450xT0.05mm,LE170
9
P-00003049
506120004300
35 FOAM,EPS-L, LE1709 P-00003051 506040005500
36 FOAM,EPS-L, LE1709 RoHS Added on 9/11/06 P-00005257 506040005500R
37
FOAM,EPS-R, LE1709
P-00003052
506040005510
38 FOAM,EPS-R, LE1709 RoHS Added on 9/11/06 P-00005253 506040005510R
39
BOX,VA702B, LE1709
P-00003056
506020006810
40 BOX,VA702b, LE1709 RoHS Added on 9/11/06 P-00008079 506020006810R
41 BAG,PE+EPE,L590xW480xT0.6mm (PRINTED)LE1 RoHS Added on 9/11/06 P-00005272 506120300400R
42 BAG,PLASTIC,l690xW(455+145)xT0.05mm, LE1 RoHS Added on 9/11/06 P-00005273 506120004500R
43 GENERIC BOX Added on 9/11/06 P-00002515 20653
44 GENERIC FOAM SET Added on 9/11/06 P-00001347 30833
45
Plastics:
RUBBER,FOOT,OD14.1xT2.5mm,3M, LE170
8
PL-00003053 503020002600
Remark 1:
Remark 2:
Electronic
Components:
Hardware:
Packing Material:
Above listed items are examples, supplier can expand the rows to add more necessary items.
All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic
Corporation. This is to eliminate repeated cross checks of each item between this version and prior versions.
ViewSonic Model Number: VS10781
RECOMMENDED SPARE PARTS LIST (VA702B-1)
Description
Accessories:
Board Assembly:
Cabinets:
Cables:
