ViewSonic VA702-1 - Page 28

ViewSonic Corporation Confidential - Do Not Copy VA702-1_VA702b-1
25
77 AD1 I/O DDR direct bus AD1; 8mA driving strength
78 AD2 I/O DDR direct bus AD2; 8mA driving strength
79 NC Not connected
80 NC Not connected
81 NC Not connected
82 NC Not connected
83 NC Not connected
84 VDDP O
Digital Output Power
85 GND Ground
86 GND Ground
87 VDDC I
Digital Core Power
88 NC Not connected
89 NC Not connected
90 NC Not connected
91 NC Not connected
92 NC Not connected
93 NC Not connected
94 VDDP O Digital Output Power
95 GND Ground
96 GND Ground
97 VDDC I Digital Core Power
98 NC Not connected
99 NC Not connected
100 NC Not connected
101 NC Not connected
102 LVA3P O
A-Link Positive LVDS Differential Data
103 LVA3M O
A-Link Negative LVDS Differential Data
104 VDDP O Digital Output Power
105 GND Ground
106 LVACKP O
A-Link Positive LVDS Differential Clock
107 LVACKM O
A-Link Negative LVDS Differential Clock
108 LVA2P O
A-Link Positive LVDS Differential Data
109 LVA2M O
A-Link Negative LVDS Differential Data
110 LVA1P O
A-Link Positive LVDS Differential Data
111 LVA1M O
A-Link Negative LVDS Differential Data
112 LVA0P O
A-Link Positive LVDS Differential Data
113 LVA0M O
A-Link Negative LVDS Differential Data
114 VDDP O Digital Output Power
115 GND Ground
116 GND Ground
117 VDDC Digital Core Power
118 LVB3P O
B-Link Positive LVDS Differential Data
119 LVB3M O
B-Link Negative LVDS Differential Data
120 LVBCKP O
B-Link Positive LVDS Differential Clock
121 LVBCKM O
B-Link Negative LVDS Differential Clock
122 LVB2P O
B-Link Positive LVDS Differential Data
123 LVB2M O
B-Link Negative LVDS Differential Data
124 LVB1P O
B-Link Positive LVDS Differential Data
125 LVB1M O
B-Link Negative LVDS Differential Data
126 VDDP O Digital Output Power
