ViewSonic Corporation Confidential - Do Not Copy VA702-1_VA702b-1
45
ViewSonic Model Number: VS10781
Serial No. Prefix: PSX
Rev: 1b
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty (PC)
1 CB-00005261
430300100210R HRN ASS'Y 1P 137mm BLACK,UL100 7 #20,RoHS For VSI&VSA 1
2 CB-00005260
430300800320R HRN ASS'Y 4x2P 189mm UL2651#28SZ504479B, For VSI&VSA 1
3 CB-00005259
430303000140R HRN LVDS FFC 30P 234mm,RoHSACCX30234KU28 For VSI&VSA 1
4 CB-00005254
453010100100R CABLE,D-SUB 15P MALE 6FT BLACK/BLUE,SZ40 For VSI&VSA 1
5 A-00003675
453070800230R PWRCORD 5A/250V BLK 6FT UK3Gx.75mm(SP60/ For Singapore 1
6 A-00006679
453070800250R PWR CORD 10A/125V BLK 6FT UL/CSA,SVT 18x For VSA 1
7 A-00003671
453070800420R PWRCORD 10A/250V BLACK 6FT SAA,H05W-F/3G For Australia 1
8 A-00006733
453070800480R PWRCORD 7A/125V BLK 6FT CNS,VCTF 3Gx0.75 For TWN 1
9 A-00006734
453070800500R PWRCORD 16A/250V BLK 6FT KTL,H05VV-F 3Gx For Korea 1
10 N/A
501010202710R BEZEL,FRONT(GRAY),VA702B,LE1709 For VSI&VSA 1
11 N/A
501020202900R COVER,BACK, LE1709 For VSI&VSA 1
12 C-00006088
501020203000R COVER,HINGE, LE1709 For VSI&VSA 2
13 N/A
501030201900R BUTTON,FUNCTION KEY, LE1709 For VSI&VSA 1
14 N/A
501120101200R LENS, LE1709 For VSI&VSA 1
15 N/A
501240201000R BASE, LE1709 For VSI&VSA 1
16 N/A
502020300700R BRACKET,LEFT, LE1709 For VSI&VSA 1
17 N/A
502020300710R BRACKET,RIGHT, LE1709 For VSI&VSA 1
18 HW-00005277
502060401900R HINGE,LEFT, LE1709 For VSI&VSA 1
19 HW-00005276
502060401910R HINGE,RIGHT, LE1709 For VSI&VSA 1
20 N/A
502080300300R SUPPORT,VESA, LE1709 For VSI&VSA 1
21 N/A
502090301300R CHASSIS, LE1709 For VSI&VSA 1
22 N/A
502170300400R PLATE,BASE,LE1709 For VSI&VSA 1
23 N/A
503010001700R RUBBER,SPACER,L25xW10xT4.0mm,LE1709 For VSI&VSA 1
24 N/A
503020002600R RUBBER,FOOT,OD14.1xT2.5mm,3M, LE1708 For VSI&VSA 4
25 N/A
505040202000R INSULATOR,MYLAR,L79.7xW62.7mm,CHASSIS, L For VSI&VSA 1
26 P-00008079
506020006810R CARTON,VA702B, LE1709 For VSI&VSA 1
27 N/A
506037003700R CARDBOARD,COVER,L1120xW980xH120xT5mm,LE1 For VSI&VSA 0.02778
28 N/A
506039001200R CORNER PAPER,820x50x50mm For VSI&VSA 0.0556
29 N/A
506039002301R CORNER PAPER,2050x50x50xT3mm,LE1705 For VSI&VSA 0.05556
30 P-00005257
506040005500R CUSHION,EPS-L, LE1709 For VSI&VSA 1
31 P-00005253
506040005510R CUSHION,EPS-R, LE1709 For VSI&VSA 1
32 N/A
506102000300R LOGO PLATE,VIEWSONIC, LE1709 For VSI&VSA 1
33 N/A
506102000400R LOGO PLATE,VIEWSONIC, LE1709(THREE BIRDS) For VSI&VSA 1
34 N/A
506102000500R LOGO PLATE,VIEWSONIC, LE1709(ELLIPSE) For VSI&VSA 1
35 P-00005272
506120300400R BAG,PE+EPE,L590xW480xT0.6mm (PRINTED)LE1 For VSI&VSA 1
36 N/A
506150001310R PALLET,1120x980x120mm,LE1709 For VSI&VSA 0.01389
37 N/A
506250005112R LBL,AGENCY(VA702B), LE1709(KOREA MARK) For VSI&VSA 1
38 N/A
506380001800R TAPE,WRAPPING TYPE,48mmx50M LE1X04/05 For VSI&VSA 0.004ROL
39 N/A
506380002100R TAPE,WRAPPING TYPE(VIEWSONIC),50mmx75M,L For VSI&VSA 0.00513ROL
40 N/A
506381000700R TAPE,ACE,45mmx30M(PC=10x45mm),LE1709 For VSI&VSA 0.001ROL
41 N/A
506390000400R LABEL,OPENING STAND, LE1709 For VSI&VSA 1
42 N/A
506390000600R LABEL,HI-POT PASS, LE1709 For VSI&VSA 1
43 N/A
506390210110R LABEL,CARTON(8ms),PRC, LE1709 For VSI&VSA 1
44 N/A
506390500100R LABEL,ENERGY STAR, LE1709 For VSI&VSA 1
45 N/A
506431000300R FILM,PE 500mmx900M For VSI&VSA 0.0004ROL
46 N/A
506440002300R LABEL,BLANK,76.2x76.2mm,LE1709(UPC) For VSI&VSA 1
47 N/A
506440002400R LABEL,BLANK,50x25mm,LE1709(S/N) For VSI&VSA 1
48 N/A
506440002600R LABEL,BLANK,210x65mm,LE1709(PALLET) For VSI&VSA 0.02778
49 N/A
506440003000R LABEL,BLANK,35x8mm, LE1709 ROHS For VSI&VSA 2
50 HW-00005270
509000000700R BOLT,#4-40x11.8,Ni FOR D-SUB/DVI CONN.RO For VSI&VSA 2
51 HW-00005271
509016304102R SCREW,I,CROSS,M3*4,Zw,ROHS For VSI&VSA 4
52 HW-00005267
509116822300R SCREW,P,CROSS,M5*22,Ni,ROHS For VSI&VSA 4
53 HW-00005269
509146305300R SCREW,PW,CROSS,W/WAS,M3*5,NI For VSI&VSA 9
54 HW-00005266
509212610300R SCREW,F,CROSS,T.T-4*10,Ni ROHS For VSI&VSA 4
55 HW-00005265
509412610500R SCREW,B,CROSS,T.T-4*10,BLK ,ROHS For VSI&VSA 4
56 N/A
511100001500R CLIP,WIRE.CH-01P(PG), LE1709 For VSI&VSA 1
57 E-00008006
631102071910R LCD PANEL 17" MT170EN01-V7-G1,AM17000057 For VSI&VSA 1
58 E-00008007
631102071920R LCD PANEL 17" MT170EN01-V7-G2,AM17000057 For VSI&VSA 1
59 E-00008008
631102071930R LCD PANEL 17" MT170EN01-V7-G3,AM17000057 For VSI&VSA 1
60 N/A
703000000510R KIT,ACCESSORY,VA702B-INL,LE1709 For VSI&VSA 1
61 C-00005262
714020002400R ASSY,BASE, LE1709 For VSI&VSA 1
62 C-00008095
714030002410R ASSY,BEZEL(G),LE1709 For VSI&VSA 1
63 C-00005264
714050002400R ASSY,BACK COVER, LE1709 For VSI&VSA 1
64 N/A
71407276B101R ASSY,FIANL(G,V7/G1&2&3),LE1709-6A0 For VSI&VSA 1
65 N/A
71408276B100R ASSY,PANEL(V7/G1&2&3),LE1709-6A0 For VSI&VSA 1
66 B-00008066
790411300630R PCBA,IF BOARD(V7), LE1709- 6A0 ROHS For VSI&VSA 1
67 B-00005279
790411400600R PCBA,PWR&INV./B, LE1709-6A0 ROHS For VSI&VSA 1
68 B-00005278 790411500000R PCBA,KEYPAD BOARD, LE1709 ROHS For VSI&VSA 1
BOM LIST (VA702B-1)
