ViewSonic Corporation Confidential - Do Not Copy VA702-1_VA702b-1
5
GENERAL specification
Test Resolution & Frequency 1280x1024 @ 60Hz
Test Image Size Full Size
Contrast and Brightness Controls
Factory Default:
Contrast = 70%, Brightness = 100%
VIDEO INTERFACE
Analog Input Connector DB-15 (Analog), refer the appendix A
Video Cable Strain Relief
Equal to twice the weight of the monitor for
five minutes
Video Cable Connector DB-15 Pin out Compliant DDC 1/2B
Video Signals Video RGB (Analog) - Separate
Video Impedance 75 Ohms (Analog)
Maximum PC Video Signal 950 mV with no damage to monitor
Maximum Mac Video Signal 1250 mV with no damage to monitor
Sync Signals LVDS
DDC 1/2B Compliant with Revision 1.3
Sync Compatibility Separate Sync
Video Compatibility
Shall be compatible with all PC type
computers, Macintosh computers, and after
market video cards
Resolution Compatibility
640 x 350, 640 x 480, 720 x 400 (640 x
400*), 800 x 600, 832 x 624, 1024 x 768,
1152 x 870, 1280 x 720, 1280 x 1024
Exclusions Not compatible with interlaced video
