Please see Panel Acceptance
Specification.
Other Panel Defects Please see Panel Acceptance
Specification.
Panel Defects Please see Panel Acceptance
Specification.
2.9 IMAGE PERFORMANCE
2.9.1 Factory Defaults
Preset Color 6500K (Primary 1)
Contrast Control Factory Default
Brightness Control Factory Default
2.9.2 Display Size
Horizontal Display Size, Primary Preset Full Screen
Vertical Display Size, Primary Preset Full Screen
2.9.3 Frame Refresh Rate
Frame Frequency Scan rate conversion shall be performed
to match input signal frame rates to VESA
1024 x 768 @ 75Hz
2.9.4 Preset Color Temperatures
Preset 1 9300K x= 0.283 +/- 0.025, y=0.298+/-0.025
Preset 2 6500K (Default) x= 0.310 +/- 0.025, y=0.330+/-0.025
Preset Color Temperature Adjustability Each color preset shall be adjustable.
Red, Green, and Blue shall be individually
controlled.
2.9.5 Video Cards Compatibility
Peaking Performance Peaking is not adjustable.
2.9.6 Raster Artifacts
Video Artifacts No Visible Streaking, Sag, or Smearing
Artifacts when driven by the specified
video cards in the primary mode and after
user adjustment to best condition.
Power Supply, and Grounding Artifacts No visible artifacts in any specified video
mode within the horizontal or vertical
frequency range of the monitor
Temperature Drift Image shall not drift or lose fine-tune
adjustment.
ViewSonic Corporation
14
Confidential --Do Not Copy VE150m/mb
