ViewSonic VE150M - Confidential - Do Not Copy

VLCD22574-XYZ Main Board
ViewSonic P/N Descri
p
tion Parts Number Location QTY UNI
E-L-0407-1413
BEAD,K5BR6H63X10X0.85-3Ts-
B,DIP 90Ζ,KING-CORE
BED-R6H63-
TS12
L3 1 PS
E-C-0404-4524
CAP,100uF,+/-20%,DIP
6.3*7,EC,16V,LEG=3-3.5mm
CAP-100U0-36A3
C1,C7,C8,C12,C160,C
181
6PS
CAP,10uF,+/-20%,DIP
180Ζ,EC,25V,LEG=3-3.5mm
CAP-10U00-32A4
C33,C49,C71,C116,C1
79,C185,C193,
8PS
E-C-0404-4472
CAP,220uF,+/-20%,DIP 180Ζ
8*7,EC,16V,LEG=3-3.5mm
CAP-220U0-3NA3
CX1,C115,C161,C162,
C166,C167,C178,C182,
C188,C189
10 PS
CNN,AUDIO(EARPHONE)JACK,L
IME
CNN-P001H-3412 J2 1 PS
M-MS-0808-6847
CNN,AUDIO(EARPHONE)JACK,L
IME GREEN
(
577C
)
,D7,d3.5,H
CNN-P001H-3402
CNN,DC JACK,2.5,DIP CNN-P001H-3431 J1 1 PS
M-MS-0808-6921
CNN,DC JACK,2.5,DIP
90Ζ,L9*H11,DJ-0702-025,JT
CNN-P001H-3401
CNN,DC JACK,2.5,DIP CNN-P001H-3441
CNN,4 PIN,2.0,DIP 180
Ζ,1 ROW CNN-P004W- CON2,CON3 2 PS
CNN,4 PIN,2.0,DIP 180Ζ,1
ROW,2002-04,UNEMAC
CNN-P004W-
2204
CNN,HEADER,6 PIN,2.54,DIP
90
Ζ,2 ROW,6P-N4
CNN-P006W-
3402
CON11 1 PS
CNN,HEADER,6 PIN,2.54,DIP
90Ζ,2 ROW,6P-N4,UNEMAC
CNN-P006W-
3401
CNN,HEADER,10 PIN,2.0,DIP
180Ζ,1 ROW
CNN-P010W-
2211
CON1 1 PS
CNN,HEADER,10 PIN,2.0,DIP
180Ζ,1 ROW
CNN-P010W-
2201
CNN,HEADER,12 PIN,2.0,DIP
180Ζ,2 ROW,12P-N8
CNN-P012W-
2214
CON4 1 PS
CNN,HEADER,14 PIN,2.0,DIP
180Ζ,2 ROW,14P-N8
CNN-P014W-
2214
CON8 1 PS
CNN,HEADER,14 PIN,2.0,DIP
180Ζ,2 ROW,14P-N8,UNEMA
CNN-P014W-
2204
CNN,HEADER,26 PIN,2.0,DIP
90Ζ,2 ROW,26P-N9
CNN-P026W-
2411
P2 1 PS
CNN,HEADER,30 PIN,2.0,DIP
90Ζ,2 ROW,30P-N16
CNN-P030W-
2411
P1 1 PS
E-D-0403-1895
DIODE,1N5822,40V,3A,DIP,2PIN,
GO TOP
DID-N5822-2601 D9 1 PS
IC,SM2965,44PIN,PLCC,5V,SMD,
SYNCMOS
IC7-0SM2965-31 U4 1 PS
INDUCTOR,150uH,0.5*60.5
TS,DIP,TCL5052-
151M050,SPORTON
IND-0150U-2601 L1 1 PS
INDUCTOR,150uH,0.5*66.5
TS,DIP,TBC1609-151K
IND-0150U-2602
B-MB-0201-0731
ASS'Y PCB
SMT,M/B(MRT/MascotV),V10,FO
R VIEW SONIC,VE150M-M
PMS-151MV-
0101
1ST
E-L-0407-1414
BEAD,FBM-10-160808-
102,SMD,0603,MID,KING-CORE
BED-102M1-1001
FB7,FB8,FB9,FB10,FB
11,FB12,FB13,
13 PS
E-L-0407-1415
BEAD,FBM-11-160808-
121T,SMD,0603,LOW,KING-
BED-121L1-1001 FB5 1 PS
E-L-0407-1410
BEAD,GT4532GA121H,SMD,453
2,MID,GOTOP
BED-121M1-6601 FB20,FB82,FB84,FB86 4 PS
ViewSonic Corporation
47
Confidential --Do Not Copy VE150m/mb
