4.1.4 P2: LCD Panel
Pin # Signal
Name
Function
1 GND GROUND
2 RB2 RED EVEN DATA SIGNAL 2
3 RB3 RED EVEN DATA SIGNAL 3
4 RB4 RED EVEN DATA SIGNAL 4
5 GND GROUND
6 RB5 RED EVEN DATA SIGNAL 5
7 RB6 RED EVEN DATA SIGNAL 6
8 RB7 RED EVEN DATA SIGNAL 7
9 GND Ground
10 GB2 GREEN EVEN DATA SIGNAL 2
11 GB3 GREEN EVEN DATA SIGNAL 3
12 GB4 GREEN EVEN DATA SIGNAL 4
13 GND GROUND
14 GB5 GREEN EVEN DATA SIGNAL 5
15 GB6 GREEN EVEN DATA SIGNAL 6
16 GB7 GREEN EVEN DATA SIGNAL 7
17 GND GROUND
18 BB2 BLUE EVEN DATA SIGNAL 2
19 BB3 BLUE EVEN DATA SIGNAL 3
20 BB4 BLUE EVEN DATA SIGNAL 4
21 GND GROUND
22 BB5 BLUE EVEN DATA SIGNAL 5
23 BB6 BLUE EVEN DATA SIGNAL 6
24 BB7 BLUE EVEN DATA SIGNAL 7
25 GND GROUND
26 GND GROUND
27 RB0 RED EVEN DATA SIGNAL 0
28 RB1 RED EVEN DATA SIGNAL 1
29 GB0 GREEN EVEN DATA SIGNAL 0
30 GB1 GREEN EVEN DATA SIGNAL 1
31 BB0 BLUE EVEN DATA SIGNAL 0
32 BB1 BLUE EVEN DATA SIGNAL 1
